P. 6

cH-47C CHTNOOK
                   SPECIFICATIONS
       Maximum All Up Weight  46,000 lb    (20,909  kg)
       Basic Weight (Crew
       and Fuel)              30,000 lb    (13,636  kg)
       Weight  unloaded       23,950 tb  '  (10,886  kg)
       Maximum Speed          175 knots  (320 km/hr)
       Dimensions:
       Length                 50 ft 9 ins   (15.24 m)
       Height                 17ft1in        (5.18m)
      widrh                   11 ft 11 ins   (3.65 m)
       Rotor tip   Rotor tip
              -
      length                  98 ft 1 0.7 ins   (30.1 4 m)
      Rotor Diameter          60 ft         (18.28 m)
      Crew                                    2 Pilots
                                     1 Flight Engineer
                                        1 Loadmaster


































      The No. 12 Squadron  Crest shows  a water  buffalo's
      head in front of two crossed boomerangs.  This
      design was chosen for the Squadron  because  it was
      the first RAAF unit based in the Northern  Territory.
      The Squadron motto is "Erramus et lmpugnamus"
      (We roam and we charge).
